1000BaseSX WDM SFP Tx:1310nm, Rx:1550nm LC/MM, 550m

1000BaseSX WDM SFP Tx:1310nm, Rx:1550nm LC/MM, 550m

$150.00

  • Supports 1000Base-SX up to 550m over either 50/125μm or 62.5/125μm Multimode fiber
  • Multi-Source Agreement (MSA) Compliant
  • Hot-pluggable
  • RoHS compliant and lead-free
  • Single +3.3V Power Supply
  • Compliant with SFF8472 diagnostic monitoring interface
SKU FO-AS40010 Category

Description

Download Specifications

Part Number TX/RX
Spectrum		 Light Source Link Power
Budget		 Typical Max. Distance Supply
Voltage		 Operating
Temp.
AS40010 Tx: 1310 nm
Rx: 1550nm		 FP laser 10 dBm 550m on 50μ or 62.5μ fiber* 3.3 V 0 ~ 70° C
AS40020 Tx: 1550 nm
Rx: 1310nm		 FP laser 10 dBm 550m on 50μ or 62.5μ fiber* 3.3 V 0 ~ 70° C

* Maximum distances attainable on multimode fiber circuits are dependent upon a circuit’s conditions; i.e., the number of splices and patch panels and the number of bends in the circuit path.
