1000LX WDM SFP Module Tx:1550nm, Rx:1310nm LC/SM, 20 km

1000LX WDM SFP Module Tx:1550nm, Rx:1310nm LC/SM, 20 km

$440.00

  • RoHS compliant
  • Meets the SFP Multi-Source Agreement (MSA)
  • Up to 20 Km link distance
  • Hot pluggable
  • Metal enclosure for low EMI performance
  • Low power dissipation
SKU FO-065-79LX2WDMB1550 Category

Description

Download Specifications

Part Number TX/RX
Spectrum		 Light
Source		 Link Power
Budget		 Typical Max.
Distance**		 Supply
Voltage		 Operating
Temp.
065-79LX2WDMA1550
(Blue clasp)		 Tx: 1310 nm
Rx: 1550 nm		 FP Laser 16 dBm 20 km 3.3V 0 ~ 70 °C
065-79LX2WDMB1550
(Green clasp)		 Tx: 1550 nm
Rx: 1310 nm		 DFB Laser 16 dBm 20 km 3.3V 0 ~ 70 °C

** Maximum distances attainable on singlemode fiber circuits are dependent upon a circuit’s conditions; i.e., the number of splices and patch panels and the number of bends in the circuit path. For comparison with competing products, please use the Link Power Budget for meaningful comparisons.
